Small Sized Manual Operation Vision Low Cost Smd Pick And Place Machine For Pcb Assembly
| CHM-T560P4 Specifications |
| Dimensions | 1180mm(L)×870mm(W)×640mm(H) |
| Weight | 140kg |
| Power Supply | AC220V (50Hz, single phase) / AC110V (60Hz, single phase); 400W |
| Air Supply | 0.5MPa~0.7MPa |
| Vacuum Generation | Built-in vacuum pump |
| Mounting Head Quantity | 4 |
| Mounting Speed | 8000cph (optimal without vision detection); 5500cph (optimal with vision detection) |
| Control Accuracy | 0.015mm |
| Component Type | 0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.) |
| PCB Thickness | 0.6mm~3.5mm |
| PCB Size | 10mm(L)×10mm(W)～400mm(L)×290mm(W) |
| PCB Conveying | Manual operation |
| Nozzle Change | Manual operation |
| Control System | Built-in computer (embedded Linux operating system), 7-inch touch screen |
| Drive System | X&Y-axis driven by stepping motors in the way of closed-loop control; Z-axis capable of reset detection; all motors adopting flexible S-curve acceleration and deceleration |
| Transmission System | Synchronous belt + linear guide |
| Feeding System | 60 Yamaha standard pneumatic/electric feeder stacks (also suitable for IC tray and stick feeder), 11 preset general IC stacks, worksurface custom IC trays supported |
| Vision System | Up-looking camara for component automatic calibration (component size applicable: 22mm×22mm); down-looking camera for PCB automatic calibration via Mark Point and component positioning |
