CHM-650 Charmhigh Smt Pick And Place Machine With Atomatic Nozzle Change

Name: CHM650 Charmhigh Smt Pick And Place Machine With Atomatic Nozzle Change
Brand: Charmhigh
Price: 1 USD

China CHM-650 Charmhigh Smt Pick And Place Machine With Atomatic Nozzle Change wholesale

Brand Name : Charmhigh

Model Number : CHM-650

Certification : CE、FCC、SGC、ISO

Place of Origin : China

MOQ : 1 set

Price : Price Negotiable

Payment Terms : T/T

Supply Ability : 20 set a month

Delivery Time : 15 work days

Packaging Details : Wooden packing

Dimensions : 1280mm(L)×1190mm(W)×1050mm(H)

Weight : 310kg

Power Supply : AC220V (50Hz, single phase), 2.1kW

Air Supply : 0.5MPa ~0.7MPa

Vacuum Generation : Vacuum generator

Mounting Head Quantity : 4

Mounting Speed : 10000cph(optimal)

Control System : Built-in industrial computer (Windows 7) equipped with monitor, keyboard, and mouse

Drive System : X&Y axis driven by servo motors;adopting flexible S-curve acceleration and deceleration

Contact Now

Update Model Electronic Products Machinery CHM-650 Charmhigh Smt Pick And Place Machine With Atomatic Nozzle Change

Charmhigh already owns 24 property rights, including 22 national patents and two software copyrights, and has passed ISO quality management system certification, EU CE certification, ROHS certification, and US FCC, SGS and other international certifications.

CHM-650 pick and place machine

It is widely used in intelligent appliance , LED , power supply, automotive electronics, main controller and etc.

FAQ:

Q:How is the training?

A:After buying our machines,your engineers can go to our company or it is so easy to operate the machine according the training video and user manual,the user manual will come with the machine together.

Q:s it hard to use these machines?

A:No,not hard at all.For our previous clients,at most 2 days is enough to learn to operate the machines.

Q:Does your machines have quality certificate?

A:Charmhigh already owns 24 property rights, including 22 national patents and two software copyrights, and has passed ISO quality management system certification, EU CE certification, ROHS certification, and US FCC, SGS and other international certifications.

Q:The Warranty of the machine?

A:One year,then the parts will be free for the buyer in the warranty.

Q:English version for these machines?

A:Yes

Product Tags:

Atomatic Nozzle Change Smt Machine

Atomatic Nozzle Change PNP Machine

CHM-650 Charmhigh Smt Pick And Place Machine With Atomatic Nozzle Change Images
