Low Cost SMT CHM-T560P4 Desktop Led Robot High Precision Pike and Place PCB ANC Machine

Product Categories

HUNAN CHARMHIGH ELECTROMECHANICAL EQUIPMENT CO., LTD.

Contact Now

Name: Low Cost SMT CHMT560P4 Desktop Led Robot High Precision Pike and Place PCB ANC Machine
Brand: Charmhigh
Price: 1 USD

Brand Name : Charmhigh

Model Number : CHM-560P4

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T

Supply Ability : 20 sets per month

Delivery Time : 15 work days

Packaging Details : wooden box

Control Accuracy : 0.015mm

PCB Size : 10mm(L)×10mm(W)～400mm(L)×290mm(W)

Control System : Built-in computer

Drive System : X&Y-axis driven by stepping motors in the way of closed-loop control;

Feeding System : 60 Yamaha 8mm standard pneumatic feeder stacks

Contact Now

Low Cost SMT CHM-560 Desktop Led Robot High Precision Pike and Place PCB ANC Machine

CHM-T560P4 Specifications
Dimensions	1180mm(L)×870mm(W)×640mm(H)
Weight	140kg
Power Supply	AC220V (50Hz, single phase) /AC110V (60Hz, single phase); 400W
Air Supply	0.5MPa ~0.7MPa
Vacuum Generation	Built-in vacuum pump
Mounting Head Quantity	4
Mounting Speed	8000cph(optimal without vision detection); 5500cph (optimal with vision detection)
Control Accuracy	0.015mm
Component Type	0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.)
PCB Thickness	0.6mm~3.5mm
PCB Size	10mm(L)×10mm(W)～400mm(L)×290mm(W)
PCB Conveying	Manual operation
Nozzle Change	Manual operation
Control System	Built-in computer (embedded Linux operating system), 7-inch touch screen
Drive System	X&Y-axis driven by stepping motors in the way of closed-loop control; Z-axis capable of reset detection;all motors adopting flexible S-curve acceleration and deceleration
Transmission System	Synchronous belt + linear guide
Feeding System	60 Yamaha 8mm standard pneumatic feeder stacks (also suitable for Yamaha electric feeder, IC tray, and stick feeder), 11 preset general IC stacks, work surface custom IC trays supported
Vision System	Up-looking camera for component automatic calibration (component size applicable: 22mm×22mm); down-looking camera for PCB calibration via Mark Point and component positioning

Low Cost SMT CHM-T560P4 Desktop Led Robot High Precision Pike and Place PCB ANC Machine
