CHM-T530P4 8000cph Mounting Speed Precision Pick And Place Machine Single Phase Power Supply

Name: CHMT530P4 8000cph Mounting Speed Precision Pick And Place Machine Single Phase Power Supply
Brand: Charmhigh
Price: 1 USD

China CHM-T530P4 8000cph Mounting Speed Precision Pick And Place Machine Single Phase Power Supply wholesale

Brand Name : Charmhigh

Model Number : CHM-T530P4

Place of Origin : China

Certification : CE、FCC、SGC、ISO

MOQ : 1 set

Price : Price Negotiable

Payment Terms : T/T

Supply Ability : 20 set a month

Delivery Time : 15 work days

Packaging Details : Wooden packing

PCB Conveying : Manual Operation

Power Supply : AC220V (50Hz, Single Phase)

Weight : 115kg

Mounting Head Quantity : 4

Control System : Built-in Computer

Vacuum Generation : Built-in Vacuum Pump

Air Supply : 0.5MPa~0.7MPa

PCB Thickness : 0.6mm~3.5mm

Contact Now

Technical Parameters:

Parameters	Details
Power Supply	AC220V (50Hz, Single Phase)
Control System	Built-in Computer
Mounting Head Quantity	4
Vacuum Generation	Built-in Vacuum Pump
PCB Conveying	Manual Operation
PCB Thickness	0.6mm~3.5mm
Weight	115kg
Mounting Speed	8000cph(optimal)
Air Supply	0.5MPa~0.7MPa

Applications:

Charmhigh CHM-T530P4 – Precision Pick and Place Machine

Charmhigh's CHM-T530P4 Precision Pick and Place Machine is engineered to bring reliable and accurate production to the electronics industry. This machine features a 0.6mm~3.5mm PCB thickness and can handle up to 8000cph with optimal performance. An air supply of 0.5MPa~0.7MPa provides the necessary pressure for accurate mounting. The built-in vacuum pump delivers the necessary suction for precise placement and the built-in computer provides the precision control for detailed accuracy. This machine is perfectly suited for a wide range of electronic production needs, making it an ideal choice for any electronics manufacturer.

CHM-T530P4 8000cph Mounting Speed Precision Pick And Place Machine Single Phase Power Supply
